P150-75

August 25, 2017 0

A lightweight construction suitable for applications where vehicular loads are not required. Contains 100 x 100mm glass lenses set into reinforced concrete ribs which are spaced at 150mm centres with an overall panel thickness of 75mm. Weight 132Kg/m². Choice of concrete colours and top surface textures. Glass lens sandblasted finishes available. Soffit finish – as…

P170-120

September 5, 2012 0

Contains 117 x 117 glass half shell paver lenses set into reinforced concrete ribs which are spaced at 170mm centres with an overall panel thickness of 120mm. Weight 195Kg/m². Choice of concrete colours and top surface textures. Glass lens sandblasted finishes available. Soffit finish – as cast / ex mould. Rib profile – square draw.…

PC170-100

August 20, 2012 0

Circular lenses provide further choices to enhance any project, this construction has been load tested and is able to sustain concentrated loadings of up to 75KN – UDL (Ultimate Design Load). Contains 117mm diameter glass lenses set into reinforced concrete ribs which are spaced at 170mm centres with an overall panel thickness of 100mm. Weight…

P165-165

August 20, 2012 0

Designed for heavy duty applications and can sustain concentrated loadings of up to 75KN – UDL (Ultimate Design Load) also providing the largest clear span of all pavement light constructions. Contains 100 x 100mm glass lenses set into reinforced concrete ribs which are spaced at 165mm centres with an overall panel thickness of 165mm. Weight…

P165-110

August 20, 2012 0

Designed for larger clear spans than P150/75 and P150/100. Sustains concentrated loadings of up to 75KN – UDL (Ultimate Design Load). Contains 100 x 100mm glass lenses set into reinforced concrete ribs which are spaced at 165mm centres with an overall panel thickness of 110mm. Weight 185Kg/m². Choice of concrete colours and top surface textures.…

P150-100

August 20, 2012 0

Maintains the visual appearance of P150/75 whilst being able to sustain concentrated loadings of up to 75KN – UDL (Ultimate Design Load). Contains 100 x 100mm glass lenses set into reinforced concrete ribs which are spaced at 150mm centres with an overall panel thickness of 100mm. Weight 171 Kg/m². Choice of concrete colours and top…
